Skandinova 78 + ALU
Windows Skandinova 78 + ALU is one of the scandinavian window profiles, based on the Skandinova 78 window structure enriched with an aluminum profile system mounted on the window from the outside. Characteristic of these windows is their design and the way of opening - to the outside, cause of the windows are additionally sealed by the wind and save free space inside the room without causing a collision when opening inside. Profile Skandinova 78 + ALU allows to use in its construction a tripple-glazed unit with a heat factor of Ug = 0,5 W / (m2K).
The wooden glued timber - pine, meranti, sapele.
The depth of the frame is 115 mm.
The depth of the wing is 78 mm.
In addition, GUTMANN NORDWIN aluminum profiles from the outside.
As a standard, double glazing 4/16/4/16/4 Ug = 0,5 W / m2K.
Optionally, panes with increased acoustic insulation parameters,
safe, tempered, anti-burglary, ornamental glass, solar protection, etc.
Standard aluminum edge frame.
Optionally for the use of warm plastic edge frame or RAL color edge frame.
Fittings in the Scandinavian standard of producer IPA and ASSA.
The system of closing on handles or stylish hooks.
Profile gasket from Dewenter or Schlegel Q-Lon.
The color of the gasket - white, brown, black, gray - depending on the color of the joinery.
No aluminum drip cap due to the aluminum profile from the outside.
The outer surface of the wing and the frame are completely covered with aluminum.
Aluminum cladding in basic RAL colors. It is possible to make an aluminum cladding
in the selected color from the RAL palette on request.
Silicone applied to our joinery only by reputable manufacturers.
Color - colorless, white, light brown, dark brown, black, anthracite - depending on the color of the joinery.
Joinery painted in lasur colors with visible wood structure from the available color palette
or any solid color from the RAL or NCS palette.
Our windows in the Scandinavian system can be made in the RETRO profile (with decorative profile on the frame and the wing) and in the MODERN profile (without a visible decorative profile). In addition, the wooden profile is covered from the outside with all aluminum.
Ways of opening windows in Scandinavian system:
|TOP HUNG||TOP SWING||SIDE HUNG||SIDE SWING|
Technical drawings - SKANDINOVA 78 + ALU - Profile RETRO
Technical drawings - SKANDINOVA 78 + ALU- Profile MODERN
Declarations of Performance - SKANDINOVA 78
Thermal Transmittance - Uw - SKANDINOVA 78
Acoustic properties - dB - SKANDINOVA 78
Available all colors from the RAL and NCS palette. Below we present the most frequently chosen colors:
